Tailings

Alfa Laval P2 and P3 decanter centrifuges are specifically designed to separate mineral ore slurries as well as tailings into solid phase and liquid phase. Separation takes place in a horizontal cylindrical bowl equipped with a screw conveyor. The feed slurry enters into the bowl through a stationary inlet tube and is then smoothly accelerated in the feed zone. Centrifugal forces of up to 3,500 G separate the solid particles from the liquid and the solids accumulate on the inner surface of the bowl.

The conveyor rotates in the same direction as the bowl, but at a different speed. This gives an axial thrust to the solid particles and the conveyor conveys those particles towards the conical end of the bowl. The solids leave the bowl through the solids discharge openings into the casing whereas the clarified liquid leaves the bowl by flowing over adjustable plate dams or power tubes into the casing.

Tailings dewatering

Alfa Laval’s solid-bowl decanter centrifuges are the perfect choice for a wide range of solid-liquid separation duties in mining and mineral applications. They can replace or complement existing solutions and help boost capacity, reduce tailings volumes, save space and increase the recovery of water, chemicals and minerals. Above all, the decanter eliminates the need for tailing damns which enhance the intrinsic safety of your operation.

Optimizing your solid-liquid separation processes is a straightforward way to cut operating and investment costs while minimizing your company’s environmental impact. In many cases you can raise plant profitability by simply adding Alfa Laval’s solid-bowl decanter centrifuges to traditional separation systems such as thickeners, sedimentation basins, filters, etc, or replace the old system altogether.
